Tenda N301 300Mbps WiFi Router – 2 Antennas, 4 Ports

The Tenda N301 is a 300Mbps wireless router designed for basic home and small office networking. It operates on the 2.4GHz band using IEEE 802.11n technology, delivering stable wireless connectivity for everyday tasks such as browsing, video streaming, and online communication.

The router features 2 external high-gain antennas that improve signal coverage and enhance wireless stability. It supports multiple operating modes including Router, Access Point, Repeater, and WISP, making it flexible for different network environments.

On the wired side, the device includes Fast Ethernet ports (10/100 Mbps), making it suitable for internet connections up to 100Mbps. It also supports PPPoE, Dynamic IP, and Static IP WAN configurations, ensuring compatibility with most ISPs.

Key Features:

1. Wireless speed up to 300Mbps (802.11n, 2.4GHz only)
2. 2× external antennas for improved coverage
3. Supports Router / AP / Repeater / WISP modes
4. WAN types: PPPoE / Dynamic IP / Static IP
5. DHCP Server for automatic IP assignment
6. NAT & Firewall for secure internet sharing
7. Bandwidth Control (QoS) for traffic management
8. Supports up to multiple connected devices (home usage)

Ports & Hardware:

1. 1 × WAN Port (10/100 Mbps)
2. 3 × LAN Ports (10/100 Mbps)
3. 2 × External Antennas
4. Reset Button

Technical Specifications:

Applications:

1. Home internet sharing
2. Small apartments
3. Basic office networking
4. WiFi range extension (Repeater mode)

Important Network Notes:

1. Works on 2.4GHz only (better coverage, lower speed than 5GHz)
2. Ports are Fast Ethernet (up to 100Mbps)
3. Ideal for internet speeds up to 100Mbps
4. Best for basic usage (not heavy gaming or high-speed fiber)
